Name: Low Cost Diffused Silicon Oil-Filled Pressure Sensor for Coffee Machine
Brand: Hefei WNK Smart Technology Co.,Ltd
SKU: WNK125SP
Availability: InStock

خونه > محصولات > سنسور فشار IOT >

Low Cost Diffused Silicon Oil-Filled Pressure Sensor for Coffee Machine

diffused silicon pressure sensor,oil-filled coffee machine sensor,IoT pressure sensor with warranty

oil-filled coffee machine sensor

IoT pressure sensor with warranty

محل منبع:

چیان

نام تجاری:

WNK

شماره مدل:

WNK125SP

با ما تماس بگیرید

درخواست نقل قول

جزئیات محصول

اتصال مکانیکی:

M6*1 ، سفارشی

رسانه قابل اجرا:

مایع، گاز

نوع فشار:

فشار سنج ، فشار مطلق

گروه خطای توالی:

%1.0 ±

محدوده فشار:

0-5bar ، 0 ~ 10bar ، 0 ~ 20bar ، 0 ~ 40bar

منبع تغذیه:

5VDC

خروجی:

0.5 ~ 4.5 ولت ، i2c

دقت:

± 1% FS

برجسته کردن:

diffused silicon pressure sensor,oil-filled coffee machine sensor,IoT pressure sensor with warranty

oil-filled coffee machine sensor

IoT pressure sensor with warranty

شرایط پرداخت و حمل و نقل

محصولات مرتبط

ویدیو

ATEX CE 4-20mA 0.5-4.5V I2C -100kpa-100MP فشار هوا آب و آب Transdeucer خلاء سنسور فشار مطلق فرستنده

بهترین قیمت رو بدست بیار

ویدیو

سنسور فشار WNK125P 0.5~4.5 ولت 150 PSI سنسور MAP سنسور فشار خودرو 5 بار

بهترین قیمت رو بدست بیار

ویدیو

سنسور فشار فشرده کم هزینه WNK 0.5-4.5 ولت برای هوا، آب و روغن

بهترین قیمت رو بدست بیار

ویدیو

سنسور فشار سیلیکون منتشر شده ۰-۲۰ بار ۴-۲۰ میلی آمپر دقت ±۰.۵%FS فولاد ضد زنگ ۳۱۶L درجه حفاظت IP65

بهترین قیمت رو بدست بیار

با ما تماس بگیرید

حالا تماس بگیرید

توضیحات محصول

WNK Low Cost Pressure Sensor for Beer Coffee Machine

Low Cost Diffused Silicon Oil-Filled Pressure Sensor for Coffee Machine 0

The WNK125PS is a diffused silicon oil-filled pressure sensor designed for automotive use. The element is made with a fully welded 316L diaphragm and doses not require and O-ring seals that could come into contact with the pressure medium, making it compatible with all types of liuqids. The absence of any moving parts results in a longer service life. With high temperature stability and accuracy, this pressure sensor is mainly used in Coffee Machine, Water Dispenser, Water Meter, automotive etc.

Applicable media	Liquid, Gas
Pressure Range	5bar,10bar,20bar,40bar
Pressure measurment	Gauge Pressure,Absolute pressure
Output	0.5~4.5V, I2C
Accuracy(linearity,Hysteresis and Repeatability)	1%F.S.(Typical)
Power supply	5VDC
Compensation temperature	-20~85ºC
Ambient temperature	-40~125ºC
Working temperature	-40~125ºC
Temperature drift(zero)	±0.15% F.S. (-20~85ºC)
Temperature drift(full range)	±0.15% F.S. (-20~85ºC)
Power(electrical) connect	Customization Connector, Cable outlet
Mechanical Connection	M6*1
Housing Material	304 stainless steel(inner core is 316 stainless steel)
Protection	IP68

Dimensions

Q: Are you trading company or manufacturer ?

A: We are a manufacturer since the year 2004, committed to producing high accuracy, long-term stability, cost-efficient pressure/level/temperature measuring instruments.

Q: What's your quality control system?

A: Our factory is cerrified under ISO 9001-2015. All products are completed with temperature compensation and 48 hours aging test before shipment.

Q: What is the warranty of your products?

A: 12 month from shipment date, for non-man-made damages.

Q: Shipping and Delivery

A: Small orders are delivered with DHL, Fedex, TNT, UPS , with delivery time in 4 - 5 business days.

Large orders are recommended to ship by sea

If you have any questions, please feel free to contact me
